APC by Schneider Electric ACF001 Airflow Cooling System, Lower Rack-Mount, 2U, 503 CFM, 3500 W, Black
APC by Schneider Electric ACF001 Airflow Cooling System, Lower Rack-Mount, 2U, 503 CFM, 3500 W, Black
Description
ACF001 Airflow Cooling System: delivers direct underfloor airflow to your rack
Pulls conditioned air into the enclosure so inlet temperatures stay steady under load
Product Overview:
If the underfloor supply wanders and equipment runs warmer than it should, this 2U unit makes the air go where it belongs. It tucks into the lower part of the cabinet and draws conditioned air straight up into your equipment, cutting down the hot exhaust recirculating back to the inlet. Recommended for racks above one-and-a-half kilowatts and capable of supporting up to three-and-a-half kilowatts, it's a practical fix for raised-floor rooms where airflow is patchy. Think steadier inlet temps, fewer surprises, and simpler thermal management when density climbs.
Key Features:
- Maximum Air Flow: Moves up to 503 CFM so conditioned air reaches equipment inlets instead of diluting with warm room air.
- Cooling Power Consumption: Built to support loads up to 3500 W, which keeps higher-density racks reliably cooled without fuss.
- Compatible Rack Height: A two-U profile mounts low in the enclosure, feeding cool air where it actually matters during busy shifts.
- Plug Type: Uses standard NEMA 5-15P and IEC 60320 C13 connections so installation ties into existing site power simply.
- UL Recognized: UL recognition gives you an accepted safety baseline, which eases approvals and keeps auditors happier.
Quick Specs:
- Brand: APC by Schneider Electric
- Manufacturer: Schneider Electric SA
- Manufacturer Part Number: ACF001
- Color: Black
- Dimensions: 16.6" x 29" x 3.5"
- Format/Type: Airflow Cooling System
- Quantity/Pack: 1 Each
- Compatibility/Use: 2U
- Country of Origin: China
- Warranty: 2 Year
Picture cooler, more predictable inlet air, hear fewer alarms, and feel the relief when racks stop flirting with thermal limits-ready to see one in your rack?
Includes the ACF001 unit, rack mounting brackets and a user manual; follow WEEE disposal rules in EU markets.
Specifications
Ships in 3-5 Bus Days
40101600
54.95lb
9.5in
32.5in
33.5in
NEW
2 years repair or replace
APC by Schneider Electric
APC by Schneider Electric
Fans
UL Recognized
Black
2U
3500 W
China
29"
Restriction of Hazardous Substances (RoHS)
Yes
3.5"
2 A
120 V
2 Year
Schneider Electric SA
ACF001
http://www.schneider-electric.com
503 CFM
Lower
- ACF001 Airflow Cooling System
- Rack Mounting brackets
- User Manual
1 each
NEMA 5-15P
IEC 60320 C13
240 W
Black
ACF001
ACF001 Airflow Cooling System
Airflow Cooling System
https://checkaproduct.se.com/DistantRequestDispatcher.aspxaction=exportPdfReach&pid=758436&lang=en-us
IEC 60320 C13
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
41.09 LB
16.6"
