- UPS circuits prevent interruption or data loss during power failures
- AVR power conditioning keeps operation during brownouts and overvoltages
- Surge-only outlets offer protection for items not requiring battery support
- AC and dataline surge suppression prevents connected equipment damage
- Perfect for protecting desktop computers, network workstations and more
Description
Desktop/Wall Mount Battery Backup Outlets: 550VA line-interactive protection
Maintains a nominal 120 volt output across an input range of 83 to 147 volts.
Product Overview:
Ever had a sudden blink wipe out a project and leave you staring at a blank screen? The Tripp Lite series AVR550U is a compact 550 VA line-interactive UPS that keeps systems alive during short outages. It maintains a nominal 120 volt output through a wide input window from eighty-three to one forty-seven volts. That means brownouts and spikes are handled without drama, and your work stays powered. Four battery-backed outlets protect critical gear while four surge-only outlets handle printers and peripherals. Mount it behind a monitor, on a wall, or set it on a shelf. It fits tight spaces and uses a six foot right-angle cord that won't block adjacent outlets.
Key Features:
- Capacity: Offers 550 VA and 300 watts, enough to keep a PC and monitor running through brief outages.
- Automatic Voltage Regulation (AVR): AVR evens out brownouts and surges so the UPS stays on battery less often, saving wear.
- Outlet Configuration: Four battery-backed outlets protect core equipment while four surge-only sockets handle printers and peripherals.
- USB & Watchdog Support: HID-compliant USB works with PowerAlert and Watchdog to shut down or reboot unattended systems cleanly.
- Form Factor & Cord: Ultra-compact desktop and wall-mount housing plus a six foot right-angle cord that avoids blocking nearby outlets.
Quick Specs:
- Brand: Tripp Lite series
- Manufacturer: Eaton Corporation
- Item#: TRP-AVR550U
- Model: AVR550U
- Series: AVR
- Color: Black
- Dimensions: 6.4" x 12" x 4.3"
- Format/Type: Line-interactive UPS
- Quantity/Pack: 1 Each
- Compatibility/Use: Printer, Speaker, Computer, Router, TV, Blu-ray Player, Gaming Console, ATM, Security System, Digital Signage, Media Center, Home/Office, Home Theater
- Country of Origin: China
- Warranty: 3 Year
Picture quiet fans, files safe and a steady screen glow-ask for unit availability or tell me which devices you want protected and I'll advise next steps?
Includes USB cable and owner's manual.
Specifications
39121011
14.25lb
4.75in
8.75in
13.50in
0.00in
T55
2-year warranty. $100,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).
Battery Backup
Printer
No
Yes
Boost +18% / Buck -15%
2 Minute
9 Minute
6 Year
Tripp Lite series
UPS Backup Systems
- Tested to UL1778 (USA)
- cUL1778 (Canada)
- NOM (Mexico)
- FCC Class B (Emissions)
- FCC Part 68
- Industry Canada (Telecommunications)
Black
6 ft
China
RJ-11
12 V dc
12"
Yes
Greater than 95% efficiency - GREEN UPS
Restriction of Hazardous Substances (RoHS)
Ultra-compact Desktop/Tower/Wall Mount
4.3"
12 A
60 Hz
120 V AC
3 Year Lifetime
550 VA
300 W
Eaton Corporation
AVR550U
10000 ft
104°F (40°C)
4
4
60 Hz
110 V AC
- Desktop/Wall Mount Battery Backup Outlets
- USB cable
- Owner's manual
1 each
Single Phase
NEMA 5-15P
Black
AVR
AVR550U
Desktop/Wall Mount Battery Backup Outlets
AVR
Line-interactive UPS
8 x NEMA 5-15R
NEMA 5-15R
No
Yes
PowerAlert UPS monitoring software
2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions
5°F (-15°C) - 113°F (45°C)
316 J
6 ms
8 Hour
Yes
Yes
Pulse-width Modulated Sine Wave
13.69 lb
6.4"
